contact usKEVA heavy duty props are correspond with the European Norm EN 1065. To satisfy any request, comipont produces three different classes, depending on vairous load capacity:
B Class, the lightest, with variable load capacity,
D Class, with 20~30 kN of load capacity,
E Class, the heaviest, with up to 40 kN of load capacity.
FEATURES
• Compliant with the EN 1065 product standard.
• Hand safety system.
• Detachment of the inner tube.
• Adjusting nuts in forged steel, handles and pins are galvanized.
• External or hidden thread.
• Customizable with personal label.
Shoring Prop Details
Name: | EN1065 Shoring Prop |
Material: | Steel Q235 |
Size: | D60/48mm, D76/63mm, D88.9/76mm |
Surface: | Electro Galvanized, Hot Dipped Galvanized, Painted, Powder Coated |
Manufacturer: | OEM is Available |
Shoring Prop Size List
Class | Series | Outer Tube [mm] | Inner Tube [mm] | Adjusting Nut | End Plate [mm] | Protection Cap | Surface Treatment | Weight [Kg] | Extension Length [mm] | Bearing Capacity [kN] |
Class B | B30 | 60.3 | 48.3 | Forged Steel | 120x120x6 | Yes | Electro Galvanized | 14.2 | 1800-3000 | 20-25 |
B35 | 60.3 | 48.3 | 120x120x6 | 16.3 | 2000-3500 | |||||
B40 | 60.3 | 48.3 | 120x120x6 | 17.69 | 2300-4000 | |||||
Class D | D30 | 76.1 | 63.5 | Forged Steel | 120x120x6 | Yes | Electro Galvanized | 17.86 | 1800-3000 | 30-40 |
D35 | 76.1 | 63.5 | 120x120x6 | 20.58 | 2000-3500 | |||||
D40 | 76.1 | 63.5 | 120x120x6 | 22.4 | 2300-4000 | |||||
D55 | 88.9 | 76.1 | 120x120x6 | 34.5 | 3100-5500 | |||||
Class E | E30 | 76.1 | 63.5 | Forged Steel | 120x120x8 | Yes | Electro Galvanized | 19.52 | 1800-3000 | ≥40 |
E35 | 76.1 | 63.5 | 120x120x8 | 22.51 | 2000-3500 | |||||
E40 | 88.9 | 76.1 | 120x120x8 | 29.4 | 2300-4000 |
Advantage:
• Simple and flexible structure
• Strong and durable
• Easy to assemble and disassemble
• Versatile with variable height adjustment
• Convenient for storage and transportation
• Economic and practical.
